Technical Data
Integrated
Integrated
(700-
(700-
3
3
T
T
ALL)
ALL)
Series
Series
9-4
#3758412 - Revision B - December, 2006
Model 700TF/I-3
FREEZER
CHARGE (R-134a Refrigerant)
NOTE: Always check serial tag for exact charge
NORMAL OPERATING PRESSURES
Low Side (at Max Speed)
High Side (at Max Speed)
COMPRESSOR
NOTE: Always check current parts price list for possible substitutions.
Service Part No.
Manufacturer
Mfg. Model No.
Original/Service Compressor Amps (at Max Speed)
Original/Service Compressor BTU/H (at Max Speed)
DEFROST METHOD
DEFROST TERMINATOR
Cut-In Temp.
Cut-Out Temp.
DEFROST HEATER
Watts
Amps
Resistance/Ohms
DRAIN TROUGH HEATER
Watts
Amps
Resistance/Ohms
FILL TUBE HEATER
Watts
Amps
Resistance/Ohms
WATER VALVE
Watts
Amps
Resistance/Ohms (Inductive)
THERMISTORS
(Evap & Compartment) Resistance/Ohms at 32°F / 0°C
9.5 oz.
5”-1 psi to 8-15 psi
75 psi to 120 psi
4203760
Embraco
VEGT-7H
~2.0 / ~2.0
850 / 850
“Adaptive Defrost”
Defrost intervals and
duration vary by unit use.
10 minute compressor
delay after each defrost.
30°F / -1°C
70°F / 21°C
400
3.48
30 - 38
80
0.70
155 - 175
4.2
.037
2830 - 3470
50
0.42
160
30000 - 33000
