Sub-Zero 700TCI-3

Sealed System Information
Integrated
Integrated
(700-
(700-
3
3
T
T
ALL)
ALL)
Series
Series
4-6
#3758412 - Revision B - December, 2006
SEALED SYSTEM REFRIGERANT FLOW DIAGRAMS
Figure 4-7. Models 700TC/I-3 and 736TC/I-3 Refrigerant Flow
FREEZER COMPRESSOR
REFRIGERATOR COMPRESSOR
REFRIGERATOR EVAPORATOR
FREEZER EVAPORATOR
CONDENSER
(FRONT - FREEZER)
(BACK - REFRIGERATOR)
FREEZER HEAT-EXCHANGER
FREEZER FILTER-DRIER
REFRIGERATOR HEAT-EXCHANGER
FRAME HEATER (HOT GAS)
REFRIGERATOR FILTER-DRIER
= REFRIGERATOR SEALED SYSTEM
= FREEZER SEALED SYSTEM
