Sub-Zero 700TCI-3

Airflow & Fan Blade Spacing
Integrated
Integrated
(700-
(700-
3
3
T
T
ALL)
ALL)
Series
Series
5-2
#3758412 - Revision B - December, 2006
Blade
Bracket
Clamp
Away From
Motor
Blade
Bracket
Clamp
Away From
Motor
UPPER FAN MOTOR
LOWER FAN MOTOR
Figure 5-1. 700TC/I-3 and 736TC/I-3 Air Flow and Fan Blade Spacing
700TC/I-3:
736TC/I-3:
1” ± 3/32”
(25.4 mm ± 0.8 mm)
7/8” ± 1/16”
(22.2 mm ± 1.6 mm)
7/8” ± 1/16”
(22.2 mm ± 1.6 mm)
