SUBITO ARGON 18 - Cable and Housing Routing - Mechanical IX Shifting; Install FD Plug and Grommet

31
13.3 Cable and housing routing – Mechanical 1X shifting
1. Install the FD plug (SKU: 81240) over the two FD hanger rivets.
Refer to page 15.
2. Install the plug grommet (SKU: 80804) in the Di2 seat tube hole and FD housing
exit hole.
3. Install a M5 plug (SKU: 80264) over the chain catcher hole.
81240
80804
80264
