SUBITO ARGON 18 - Rear Wheel Installation (Cassette Installation); Use Magnet Locknut; Torque Cassette Locknut

43
17.2 Rear Wheel Installation (Cassette Installation)
1. You will need to replace the the lockring supplied with the cassette
and use the magnet locknut (SKU: 81227).
2. Place the cassette on the cassette body, aligning the spline.
3. Grease the threads of the magnet locknut.
4. Screw the magnet locknut in place.
5. Torque to 40Nm.
Rear Wheel
Supplied
with cassette
81227
81227
4
4Nm
4
3Nm
3Nm
2
2Nm
3
3Nm
5
9.5Nm
4
5Nm
2
HT
8
12Nm
8
35Nm
2.5
2Nm
2
0.5-1Nm
40Nm
4Nm
T25
T25
IMPORTANT:
Use the supplied cassette Magnet lock nut
(SKU: 81227). Without it (SKU: 81227), the
ebikemotion system will not recognize the
pedaling movement and will not provide
any assistance.
