42 910R/950R/950T/970T - OPERATION
CHOOSE ANTENNA CONFIGURATION
42 910R/950R/950T/970T - OPERATION
CHOOSE ANTENNA CONFIGURATION
Advantages/Disadvantages
Read the descriptions below and determine the antenna
configuration that best fits your job.
Antenna Advantages Disadvantages
single peak more range less precise
twin peak most precise less range
null sharp response easily distorted in congested
areas
left/right easy to use for
most locating
jobs
easily distorted in congested
areas
