Subsite 910R - 970 Transmitter

910R/950R/950T/970T - SPECIFICATIONS 67
970 TRANSMITTER
910R/950R/950T/970T - SPECIFICATIONS 67
970 TRANSMITTER
970 TRANSMITTER
Dimensions U.S. Metric
Length 14 in 355 mm
Width 4.2 in 107 mm
Height 11 in 280 mm
Operating weight 7.25 lb 3.3 kg
Operation U.S. Metric
Operating temperature range -4°F to
122°F
-20°C to
50°C
Maximum power output 5 watts 5 watts
Operating modes (some optional*) : 512 Hz, 1 kHz, 8 kHz, 29 kHz,
80 kHz, 200 kHz*, and dual (8 kHz and 29 kHz)
Timer: unit runs continuously or shuts off after running for selected hour
interval (8-hour maximum)
Batteries
Batteries 8 D-cell alkaline
Battery life (continuous use at power level
2)
approximately 80 hours
