64 910R/950R/950T/970T - SPECIFICATIONS
950 RECEIVER
64 910R/950R/950T/970T - SPECIFICATIONS
950 RECEIVER
Operation U.S. Metric
Operating temperature range -4°F to
122°F
-20°C to
50°C
Antenna configurations single peak, twin peak,
null, left/right (line only)
Audio output speaker
Operating modes (some optional*)
Active line: 400 Hz*, 512 Hz, 560 Hz*, 815 Hz*, 1 kHz, 8
kHz, 29 kHz, 80 kHz, 200 kHz*, 33 kHz (EML)
Beacon (locate/depth only): 512 Hz*, 29 kHz*, 33 kHz*
Passive line: 50 Hz, 60 Hz, 50 P power*, 60 P power*,
31 kHz*
Radio: passive locate only, no depth available*
Locating ranges
Lines 15 ft 4.6 m
Beacons 10 ft 3 m
Maximum depth ranges**
Passive line ±10% .5 - 10 ft .15 - 3 m
Active line ±3% .2 - 5 ft .06 - 1.5 m
Active line ±5% 5 - 10 ft 1.5 - 3 m
Active line ±10% 10 ft and
deeper
3 m and
deeper
Beacon ±5% .5 - 10 ft .15 - 3 m
LCD backlight LED (green)
External ports RS-232 serial
**Locators are calibrated to these tolerances under ideal test field conditions.
Actual operating field conditions may have signal distortions or may contain
noise sources which result in depth estimate accuracy that is less than specified.
