Section 7
ILLUSTRATIONS AND PARTS LIST
39
7.3 ENGINE, COMPRES SOR A ND PARTS --- J OHN DEERE --- 18 5 MODELS
key part
number description number quantity
1 key,square 250040---924 1
2 spacer, brake lever 250028---681 2
3 engine, Consul t Fac tor y 1
4 valve, air inlet
(I)
02250088---348 1
5 valve, oil drain 250037---542 1
6 tube, steel 250011---577 1
7 o---ring, neoprene 826202---238 1
8 mount, vibration 047630 4
9 mount, vibration 047628 4
10 hose, fuel line (ft) 842315---038 1
11 spacer 02250064---594 2
12 drainlock 040061 1
13 spacer, fan 409984 1
14 coupling
(II)
250034---921 1
15 fan,suction 250005---178 1
16 bushing, tapper 250035---375 1
17 bracket, 02250094---233 1
18 support 02250061---551 1
19 adapter 040292 1
20 sub assembly, control cylinder 02250085---731 1
21 pin,drive 250035---041 8
22 switch, engine temp 02250098---484 1
23 bracket 02250094---017 2
24 compressor & parts
(III)
251270---001 1
25 sub assembly, regulator valve
(IV)
250040---047 1
26 bracket 02250094---234 1
27 adapter 02250071---119 1
28 connector, straight 1/4 t pls 1/4 npt m 250018---428 1
(Continued on Page 41)
(I)
For maintenance on inlet valve 02250088---348, order repair kit no.250019---451.
(II)
For maintenance on coupling 250034---921, order repair kit no.250041---801.
(III)
There isanexchange programwhereby aremanufactured compressor unit can beobtained fromSullair
distributors orthe factoryat less costthan the owner could repair the unit. Forinformation regarding the
unit exchange program, contact your nearest Sullair representative or the Sullair Corporation.
The shaft seal is not considered part of the compressor unit in regard to the two year warranty. The nor-
mal Sullair parts warranty applies. For shaft seal repair s c onsult factor y.
(IV)
SEE SECTION 7.7C..
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
