Section 8
ILLUSTRATIONS AND PARTS LIST
59
8.5 COOLING AND LUBRICATION SYSTEM- AIR-COOLED
key part
number description number quantity
1 reducer, straight thread 1 1/2” x 1 1/4”
(150 HP) 870024-020 2
•reducer, straight thread 1 1/2” x 1 1/4”
(200 HP) 870024-020 3
2 elbow, tube 1 1/4” 811620-162 (150 HP) 2
•elbow, tube 1 1/4” 811620-162 (200 HP) 3
3 connector, tube 1 1/4” x 1 5/8” (150 HP) 811820-163 4
•connector, tube 1 1/4” x 1 5/8” (200 HP) 811820-163 3
4 tube 02250123-356 1
5 union, tube hex 1 1/4” 811320-125 2
6 tube, (150 HP) 02250125-144 1
•tube, (200 HP) 02250123-352 1
7 tube 02250123-346 1
8 tube, (150 HP) 02250123-354 1
•tube, (200 HP) 02250123-350 1
9 tube 02250123-344 1
10 filter, fluid 1 5/8” (I) 02250054-605 1
11 adapter, SAE 1 5/8” x 1 5/8” 02250055-015 2
12 valve, oil stop (II) 02250113-668 1
13 housing, thermal valve 1 5/8”(III) 02250092-929 1
14 seal, U-cup viton 02250101-372 1
15 element, thermal valve 049542 1
16 O-ring, viton 2 1/2” x 3/32” 826502-144 1
17 washer, springlock 3/8” 837806-094 4
18 capscrew, ferry 3/8”-16 x 1 1/2” 867306-150 4
19 connector, tube 1 1/4” x 1 5/8” (150 HP) 811820-163 1
•connector, tube 1 1/4” x 1 1/2” (200 HP) 811820-188 1
(I) For maintenance of fluid filter no. 02250054-605, order repair kit no. 250025-526.
(II) For maintenance of stop valve no. 02250113-668, order repair kit no. 02250116-697.
(III) For maintenance on thermal valve, order replacement element no. 02250105-553.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
