Section 8
ILLUSTRATIONS AND PARTS LIST
67
8.9 AIR PIPING SYTEM- 150-200HP
key part
number description number quantity
1 plate, supt-cust conn moist drn 02250112-255 1
2 valve, ball 3/4” npt apollo 02250117-792 1
3 tube, mpv/clr LS16T 02250134-840 1
4 tube, clr/moist sep - LS16T 02250134-910 1
5 tube, moist drn - LS16T 3/4” 02250134-934 1
6 support, moist sep LS16T 350psi 02250134-953 1
7 gasket, asa flange 300# 1-1/2” 240620-005 2
8 separator, water 1-1/2” w-a 31l 250001-873 1
9 trap, auto 3/4”npt 400# max 250006-639 1
10 union, pipe-brs seat 3/4 300# 805730-030 1
11 elbow, red 2 x 1 1/2 300# 806808-150 1
12 connector, tube-m 2 x 2 810232-200 2
13 elbow, tube 90 deg m 3/4 x 3/4 810512-075 2
14 elbow, tube 90 deg m 2 x 2 810532-200 2
15 flange, thrd 1 1/2” 300# rf 820330-024 2
16 nut, hex pltd 5/16-18 825205-273 2
17 nut, hex pltd 1/2-13 825208-448 4
18 nut, hex pltd 3/4-10 825212-665 8
19 u-bolt,1/2” x 5” pipe 829008-500 2
20 capscr, hex gr5 5/16-18 x 1 1/4 829105-125 2
21 capscr, hex gr5 1/2-13 x 1 1/2 829108-150 4
22 capscr, hex gr5 3/4-10 x 2 3/4 829112-275 8
23 washer, spr lock reg pltd 5/16 837805-078 2
24 washer, spr lock reg pltd 1/2 837808-125 8
25 washer, spr lock reg pltd 3/4 837812-188 8
26 washer, pl-b reg pltd 5/16 838205-071 2
27 washer, pl-b reg pltd 1/2 838208-112 8
28 bulkhead, pipe 3/4” npt 841500-012 1
29 nipple, pipe-xs plt 3/4 x 1 1/2 866412-015 2
30 nipple, pipe-xs plt 3/4 x 2 866412-020 1
31 nipple, pipe-xs plt 3/4 x 3 866412-030 1
32 nipple, pipe-xs plt 1 1/2 x 2 866424-020 2
33 bushing, red pltd 1 x 3/4 867104-030 1
(Continued on page 69)
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
