Section 8

ILLUSTRATIONS AND PARTS LIST

8.12 DISCHARGE SYSTEM

key part

number description number quantity

1 sub assembly, vlv assy 3” npt x 3” npt disch (I)(II) 016732B 1

2 connector, flex 1/4t x 1/4p 020169 4

3 ring, hldwn & crsmbr assy. 02250044-376 1

4 plug, sight glass 1-7/8” sae 02250097-611 1

5 support, bracket oil return ls12/16 02250101-192 1

6 connector, tube male bhd 1/4 x sae 02250101-490 1

7 filter, asembly genisis filter 02250117-782 2

8 valve, ball 3/4” npt apollo 02250117-792 1

9 orifice, plug brass 1/8”npt x 1/32” 02250125-774 1

10 orifice, plug brass 1/8”npt x 1/16” 02250125-775 1

11 sightglass, orf block sae 02250126-129 2

12 tank, air-oil separator LS16T 02250134-216 1

13 pipe, assembly LS16T disch-tank in 02250134-842 1

14 pipe, assembly LS16Tdisch vlv out 02250134-843 1

15 boom, LS16T sump head lifting 02250135-164 1

16 valve, relief 1” npt 400psi 02250137-688 1

17 sleeve, rtd 1/2”npt ls20t disch 02250138-457 2

18 plug, o-ring boss sae 1 1/4 040029 1

19 valve, pneu (nc) 500# rn bdv (III) 045116 1

20 gasket, asa flange 300# 2-1/2” (II) 240620-007 2

21 gasket, asa flange 300# 3” (II) 240620-008 1

22 adapter, di vlv-assy ddh20 250002-048 1

23 gasket, sep cover hi pressure (IV) 250006-536 1

24 valve, mp/chk 2”350#wp(157#mp) (V) 250022-735 1

(Continued on page 77)

(I) For maintenance on inlet assembly valve no. 01673B, order repair kit no. 606208-001.

(II) When performing maintenance on inlet assembly valve, if required, order 2 1/2” gasket no. 240620-007,

and 3” gasket no. 240620-008.

(III) For maintenance on pneumatic valve no. 045116, order repair kit no. 047524.

(IV) When performing maintenance on separator elements, if required, order (lid cover) gasket no. 250006-

536.

(V) For maintenance on minimum pressure check valve no. 250022-735, order repair kit no. 250022-736.

PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR

Sullair LS16T User Manual
