Section 2
SEQUENCING WITH
MULTIPLE CONTROLLERS
13
2.13.2 SUPERVISOR II DELUXE P2 PRESSURE TRANSDUCER CALIBRATION
Perform the following steps to calibrate the Supervisor II Deluxe Controller pressure
reading:
1. Measure the pressure using an independent certified gauge.
2. Enter the following special key sequence to enter the Calibration menu: Logo
, Up
arrow
, Display , Lamp Test , Program .
3. Ensure that the first line of the display reads CAL P1, if not push the Display
key and
enter the above key sequence again.
4. When the first line of the display reads CAL P1 push the Program
key. The first line
of the display will then read CAL P2. The second line of the display will show the
calibration parameter (range +7 to -7) and the current P2 pressure reading.
5. Change the calibration parameter for P2 so that the pressure value at the Controller
reads the same as the gauge.
a. Use the Up
arrow key to increase the reading and the Lamp Test key to
decrease the reading.
b. Push the PROGRAM
key. The Program key must be pressed after setting
the calibration parameter to make it permanent.
6. Recheck the pressure to ensure the display reading is correct.
2.13.3 WS CONTROLLER P2 PRESSURE TRANSDUCER CALIBRATION
Perform the following steps to calibrate the WS Controller pressure reading:
Calibrate the WS Controller P2 pressure using the WS PC User Interface. Refer to the
WS PC User Interface Manual for details.
Recheck the pressure to ensure the display reading is correct.
2.14 FULL LOAD FEATURE
The full load feature energizes a solenoid valve on the machine that forces the base
machine(s) to full load when being sequenced. Spiral valve machines may also require a
relay that de-energizes the spiral control solenoid valve during full load mode.
