14
Section 4
OPERATION WITH REMOTE CONTROLLERS
to be entered, position to the character space with the Right and Left arrow keys.
Adjust the value with the Up and Down keys. To save the changed value, push the
Enter key.
Select the sequencing group, and adjust Sequence by. Select the REMOTE mode. This
enables three digital inputs for Remote Start/Stop, Unload/Load and Master Control. These
inputs are normally controlled by remote relay contacts or a PLC controller. The Supervisor
may then be interfaced with custom sequencing panels, which provide signals for a 2-wire
stop/start operation. The remaining adjustments in the sequencing group have no effect in
REMOTE mode.
4.3 CONTROLS WIRING AND ADJUSTMENT – SUPERVISOR II DELUXE
There are three inputs and one output that are enabled in this mode:
Remote Start/Stop Input D10 J3-19
Remote Load/Unload Input D9 J3-18
Local/Master Input D8 J3-17
Local/Master Output K6 J1-14,15
Inputs D8, D9 and D10 are wired through customer furnished relay contacts to ground
(Supervisor II Deluxe Common J3-20). If D10 is open the machine will stop, and be held
stopped. If D10 is grounded the machine will be enabled to start. If remote start/stop is not
needed then jumper D10 (J3-19) to GND (J3-20). The following table describes how the
other inputs work when D10 connected to GND J3-20:
Local/Master Load/Unload Operation
Open Open Normal load and unload
Open Closed Force unload
Closed Open Force load, unload at P1 max - 3
Closed Closed Force unload
The Local/Master Output is on when the Local/Master Input is on and the machine is not in
E-stop or Stop. If the Local/Master output is on the display will have two stars (**) in the mid-
dle of the bottom line. The Local/Master Output is a relay contact that can handle 250VAC
at 8 amperes. (J1-14 & J1-15)
To change parameters on the Supervisor II Deluxe, push the Program key until the top
line of the display identifies the parameter to be changed. The Up arrow and Logo
keys will increment the parameter value; the Lamp Test will decrement. Push
the Program key to save the changed value. The next parameter will then be dis-
played. From the main screen, press the program key 9 times and adjust SEQUENCE.
Select the REMOTE sequencing mode. This enables three digital inputs for Remote
Start/Stop, Unload/Load and Master Control. These inputs are normally controlled by remote
relay contacts or a PLC controller. The Supervisor may then be interfaced with custom
sequencing panels, which provide signals for a 2-wire stop/start operation.
