Sullair Supervisor - Page 4

TABLE OF CONTENTS
PAGE
Section 3
SEQUENCING WITH VARIABLE SPEED DRIVE COMPRESSORS
11 3.1 VARIABLE SPEED DRIVE APPLICATIONS
11 3.2 SETUP FOR FIXED SPEED MACHINES
AND A VSD COMPRESSOR
12 3.3 SETUP FOR MULTIPLE VSD COMPRESSORS
Section 4
OPERATION WITH REMOTE CONTROLLERS
13 4.1 NORMAL OPERATION
13 4.2 CONTROLS WIRING AND ADJUSTMENT-
SUPERVISOR
14 4.3 CONTROLS WIRING AND ADJUSTMENT-
SUPERVISOR II DELUXE
Section 5
SEQUENCING TIMERS
15 5.1 RECOVERY TIME & DELAYED START TIMER
16 5.1.1 Example 1: Unload Operation
16 5.1.2 Example 2: Load Operation
17 5.1.3 Example 3: Starting Example
(pressure drops below lowest pressure setting)
17 5.1.4 Example 4: Starting Example
(pressure between lowest and load pressure setting)
19 5.2 SUMMARY
Section 6
SUPERVISOR PROTOCOL
21 6.1 OVERVIEW
21 6.2 ADVANTAGES OF BROADCAST MODE
22 6.3 RS-486 SERIAL CHANNEL
22 6.4 TIME SLICING OF THE RS-485 SERIAL
CHANNEL
Continued...
