Section 3
27
TS32 USER MANUAL
SPECIFICATIONS
3.1 TABLE OF SPECIFICATIONS—TS32
3.2 COMPRESSOR SPECIFICATIONS
Model Hz
DIMENSIONS (I)
Length Width Height
Weight
in cm in cm in cm
TS32 AC 50/60 154 392 78 198 86 218
(II)
TS32 WC 50/60 154 392 78 198 86 218
(II)
(I) Dimensions for enclosed model
(II) Consult factory.
NOTE
Noise levels vary with machine and enclo-
sure. For machine dBA output, consult
factory with machine serial number.
COMPRESSOR: STANDARD MODELS:
Type: Positive displacement, fluid-lubricated, twin rotary screws
Configuration: Two-stage tandem, geared integral drive
Bearing Type: Anti-friction
Cooling: See Section 2.3
Lubricant: Pressurized fluid - see sections Section 3.4, Section 3.5 and Section 3.6
Sump Capacity: 24 gallons/91 liters for 200/250HP, 35 gallons/ 132.5 liters for 300/350HP
System Fluid Capacity: Varies by cooling type - see Section 4.7
Duty Pressure: 100-110 psig (6.9-7.6 bar), other pressures available
Control Type: Spiral valve, Electro - pneumatic
Options:
24KT lubricant, Cold Weather Package, EES Remote Heat Recovery,
Enclosure, Phase Monitor Relay, Remote Air Cooler, Water Solenoid
Valve, Water Regulator Valve
