SECTION 3 TS32 USER MANUAL
33
Figure 3-2: Identification—Water-Cooled
INSTALLATION NOTE:
A FOUNDATION OR MOUNTING CAPABLE OF SUPPORTING THE
WEIGHT ( 12,160# ) OF THE MACHINE AND RIGID ENOUGH TO MAIN-
TAIN THE COMPRESSOR FRAME LEVEL AND THE COMPRESSOR IN
ALIGNMENT IS REQUIRED. THE COMPRESSOR FRAME MUST BE LEV-
ELED AND SECURED WITH FOUNDATION BOLTS, AND FULL UNIFORM
CONTACT MUST BE MAINTAINED BETWEEN THE FRAME AND FOUN-
DATION. IT IS RECOMMENFED THAT THE FRAME BE GROUTED TO
THE FOUNDATION. THE COMPRESSOR UNIT AND DRIVER MUST BE
ALIGNED AFTER THE FRAME INSTALLATION IS COMPLETED AS SPEC-
IFIED IN THE OPERATORS MANUAL. NO PIPING LOADS SHALL BE
TRANSMITTED TO THE MACHINE BY EXTERNAL CONNECTIONS.
NOTES:
1. ALLOW 4 FT. MIN. CLEARANCE ALL AROUND FOR ACCESS,AS
WELL AS FREE CIRCULATION OF AIR.
2. ALL DIMENSIONS ARE +/-.5 INCH.
