Sullair TS32 Series User Manual

SECTION 3 TS32 USER MANUAL
35
Figure 3-3: Piping and Instrumentation Diagram—Air-Cooled
KEY
NO.
PART NO.
200/250HP
PART NO.
300/350HP
Q
T
Y
DESCRIPTION
1 250006-718 250006-718 1 FLTR,INL OPTIMALAIR
2 02250126-220 02250126-220 1 VLV,10" INL BTFLY TS32C
3 011682-003 011682-003 1 CONTROL, SULLICON LESS BRKT
4 408893 408893 2 VALVE, SHUTTLE 1/4" (DBL CHK)
5 - - 1 VLV, SPIRAL
6 02250148-608 02250148-608 1 VLV,PRESS REG 1/4" NPT
7 02250125-657 02250125-657 1 VLV,SOL 3WN0 1/4 235# N4
8 02250112-032 02250112-032 2 FLTR,CONTROL AIR 1/4"NPT
9 02250148-609 02250148-609 1 VLV,PRESS REG 1/4" NPT 70-250
10 02250125-774 02250125-774 1 ORF,PLUG BRASS 1/8"NPT X1/32
11 02250101-191 02250101-191 1 ORF,.031 BRASS 1/4MNPT
12 044912 409783 1 VALVE, 2-WAY PNEUMATIC
13 02250132-934 02250132-934 1 ORF,CAP 031 X 1/4"NPT
14 02250125-679 02250125-679 2 VLV,SOL 2WNC 1/4 150# N4
15 02250155-174 02250155-174 4 XDCR,PRESS 0-250# RATIOMETRIC
16 02250125-776 02250125-776 1 ORF,PLUG BRASS 1/8"NPT X 3/32
17 02250126-129 02250126-129 2 GL,SIGHT/ORF BLK-SAE
18 02250117-782 02250117-782 2 FLTR,ASSEMBLY GENISIS FILTR
19 250033-821 250033-821 1 VALVE, MIN PRESS CHECK 3"
20 041111 041111 1 VALVE, DRAIN-SELF CLOSE 1/8NPT
21 250034-133 250034-129 1 ELEMENT, SEP/SEC
22 250034-121 250034-123 1 ELEMENT, PRIMARY 25-200
23 02250117-009 02250117-009 2 GA,PRESS LIQ FILL PSI/BAR 2.5"
24 02250179-431 02250179-431 4 P,THERMISTOR 3000 OHM NTC
25 02250092-138 02250092-138 1 VLV,PRESS RLF 1/2"NPT-150 PSIG
26 02250119-109 02250119-109 1 VLV,RLF 1-1/2" 150# 1950CFM
27 02250120-350 02250120-612 1 TNK,OIL SUMP
28 02250097-611 02250097-611 2 PLUG,SIGHT GLASS 1 7/8" SAE
PLEASE NOTE: WHEN ORDERING PARTS,
INDICATE SERIAL NUMBER OF COMPRESSOR
29 02250125-221 02250125-221 1 VLV,BALL 3/4"SAE X 3/4"NPT
30 250029-330 250029-330 1 VLV,RLF 2" X 2 1/2"
31 242221 242221 1 RESERVOIR, AIR 415 CU.IN.
32 02250127-119 02250120-955 1 SA,THRM VLV
33 02250121-658 02250121-638 1 FLTR,1 7/8-12 SAE CORELESS
34 02250182-545 02250182-545 1 DRN,ZERO LOSS 115V 1/2"NPT
35 02250122-858 02250122-218 1 CLR,OIL
36 02250121-098 02250122-219 1 AFTERCOOLER
37 02250166-744 02250166-744 1 SEP,WTR SCWS-1700N 2 1/2”
38 02250113-668 02250122-004 1 VLV,OIL STP CI 1 7/8-12 PORTS
39 047117 047117 1 VALVE, BALL 1/2 NPT
40 02250078-249 02250078-249 1 SW,VAC 22"WC N4 6FT CABLE
41 02250182-548 02250182-548 1 VLV,BALL/STNR COMBO-1/2"NPT
42 - - 1 UNIT, COMPRESSOR
43 02250125-657 02250125-657 1 VLV,SOL 3WN0 1/4 235# N4
44 02250110-557 02250110-557 3 VLV,CHK 1/4"NPTF VITON SEAT
45 02250184-677 02250184-677 1 HTR,JZL DRAIN 115V 50W
46 047226 047226 1 HEATER, DRUM-115V 1000W
47 046556 046556 2 REGULATOR,PRESS-1/4NPT
48 042034 042034 1 TRAP, AUTOMATIC 3/4" 150#
49 02250170-782 02250170-782 1 VLV,DR COMBO 115 VAC
Continued on page 37
KEY
NO.
PART NO.
200/250HP
PART NO.
300/350HP
Q
T
Y
DESCRIPTION
PLEASE NOTE: WHEN ORDERING PARTS,
INDICATE SERIAL NUMBER OF COMPRESSOR
