SECTION 3 TS32 USER MANUAL
45
Figure 3-6: Piping and Instrumentation Diagram—Water-Cooled
COMP DESCRIPTION
P1 WET SUMP PRESSURE
P2 LINE PRESSURE
P3 INJECTION FLUID PRESSURE
P4 HIGH PRESSURE SIDE OF FLUID FILTER
PSW1 INLET FILTER VACUUM SWITCH
PSW2 WATER PRESSURE SWITCH
SOL1 LOAD/UNLOAD SOLENOID VALVE
S O L 2 S P I R A L C O N T R O L S O L E N O I D V A L V E ( O P T I O N A L )
S O L 3 S T A R T C O N T R O L S O L E N O I D V A L V E ( O P T I O N A L )
SOL4 MEC/SEQUENCING/FULL LOAD SOLENOID VALVE
(OPTIONAL)
S O L 5 C O M B O D R A I N / J Z L D R A I N S O L E N O I D V A L V E
S O L 6 W A T E R S H U T O F F S O L E N O I D V A L V E ( O P T I O N A L )
T1 WET DISCHARGE TEMPERATURE
T2 DRY DISCHARGE TEMPERATURE
T3 INJECTION FLUID TEMPERATURE
T4 INTERSTAGE AIR/FLUID TEMPERATURE
HTR1 SUMP HEATER
HTR3 TRAP HEATER
NOTES:
1. PART NUMBERS ARE FOR REFERENCE ONLY. REFER TO BILL OF
MATERIAL AND OR FACE OF ORDER FOR ACTUAL PARTS.
2. SECTION BETWEEN LETTERED POINTS ARE TO BE REPLACED
WITH CORRESPONDING OPTION PICTURED BELOW, AS
REQUIRED BY FACE OF ORDER.
3. CONTROL LINES ARE 1/4" TUBING EXCEPT AS NOTED.
4. OPTIONAL HEAT TRACE IS APPLIED ONLY TO CONTROL AND
MOISTURE DRAIN LINES AND USED ONLY WITH STAINLESS
STEEL TUBING. REFER TO FACE OF ORDER FOR HEAT TRACE
REQUIREMENTS.
5. PART VARIES BY MODEL.
