25
8-6) Maintenance of Variator Bearing
• Maintenance of bearing is needed for BEILER vertical A Type and B Type .
• Replenish grease from grease nipple (Fig 30 on page 35.)
Table 33 Interval
(2) Recommended Grease
Table 34 Recommended Grease
Ambient temperature
-10–50
Cosmo Oil
COSMO GREASE
DYNAMAX SH No.2
• Do not use any grease other than those shown in Table 34.
(4) Supply and Discharge of Grease (Refer to Fig.30 Construction on page 35)
Replenish the new grease from the grease nipple during the operation.
(Replenishing grease while BEIER is nonoperational may cause insufficient grease exchange.)
(1) Interval
• Excessive grease may cause temperature rise of the bearing or leakage of the grease.
• Do not extend the replenishing interval by supplying more than the prescribed amount of grease.
• Omitting to replenish grease at the start or periodically may result in abnormal abrasion, noise, and breakage of the
bearing.
(3) Grease Quantity
Table 35 Amount of Grease to Be Replenished on Open Bearing
Frame size
BEIER A and B Type (vertical)
N10A N8B
15A 10B
20A 15B
30A 20B
40A 30B
50A 50B
75A 75B
100A
150A 100B
200A 150B
Basic type
BEIEL-CYCLO Variator
For output shaft
Bearing No.
6208NR
6310NR
6313NR
22217BK
23024BK
23128BNR
20
35
25
35
100
NU312
NU314
NU317
—
—
30
40
55
—
—
6315Z
6317Z
6320Z
—
—
45
55
70
—
—
5 ————
Qty of grease (g)
Input shaft side
Bearing No. Qty of grease (g) Bearing No. Qty of grease (g)
Output shaft side
For slow speed shaft
With built-in gear
• Replenish the amount of grease in the table above to the bearings.
• Replenish grease at least every three years even if you use the unit with the intermittent opration.
• After a long suspension, replenish grease right after starting the operation.
COMMON
Hours of
operation
10 hr max./day
10–24 hr/day
Replenishment
interval
3–6 months
Remarks
Reduce the supply inter-
val when the operating
conditions are severe or
the frame size is large.
500–1,000 hr
