CONSTRUCTION

Fig. 21 RNFM series

Fig. 22 RNYM series

Part

Description

No.

1 Case (1)

2 Gear

3 Pinion shaft

4 Gear

5 Pinion shaft

6 Hypoid pinion shaft

7 Bearing metal

8 Bearing metal

9 Hypoid gear

10 Output shaft

11 Oil seal

12 Case (2)

Table 21 Main Parts
