39 | P a g e
Two variations of Insert
There are two internal inserts supplied with each Sumo ORGA. A long insert is
used to reduce (approximately half) the seed rate for very low seed rates e.g.
Oilseed Rape, Grass or Linseed. The inserts also act as a guide to align the Sumo
ORGA. The Short Insert has no effect on seed rates and purely aligns the end of
the Orga flighting.
Long Insert Short Insert
Gears are interchangeable
between the Motor Shaft and
Sumo ORGA shaft to achieve
a wide range of seeding
rates. e.g. 3:1 gearing can be
swapped to achieve 1:3. Each
Metering Unit is supplied
with a large and a small gear.
Agitation unit has two positions,
‘in work’ (illustrated) and ‘out of
work’. These positions are
secured with a lynch pin.
Blanking slide for isolation
of Orga from tank
contents.
