Seed Depth
The seeding depth is altered by removing a 20mm pin and lifting or lowering the
coulter. For bean drilling a 1” seed boot can be fitted by removing roll pin.
5.2.5 DD Coulter Overview
Leading Disc
The leading disc is in a fixed position and can only be adjusted via the
hydraulically controlled coulter height.
Gauge Wheel
Leg
5’’ Seed Boot as Standard
(For options see Section
7.1.)
Seed Hose Outlet
Contour following pressure ram
Rear Closing/Firming
Wheel
Gauge Wheel Handle
Seed
Tab
Leading Disc
Gauge
Wheel
