SUNBA Lite Series - 5. Mounting Outdoor; Power of Ethernet (PoE) Wiring; Non-PoE (DC12 V) Wiring

Please complete bench test (see Chapter 1) before mounting the camera outdoor.
100V~250V
Data out
Data in
Router
POE+out
POE+
802.3at
100~250ft
POE
ELV (Extra-Low Voltage System)
Wiring method:
Injector/Swith
- 12 -
5. Mounting Outdoor
Wiring Type A: Power of Ethernet Solution
100V~250V
Data in
Router
Non-PoE
ELE (Force Electricity)
Wiring method:
≥18 wire gauge
DC 12V
Power Adapter
Wiring Type B: Non-PoE (DC12V) Solution
