SUNBA Performance Series - Video and Image Setting

Video
Compression
Parameter Configuration
Frame Rate
Bitrate Type
Image Quality
I Frame
Interval
GOP
SVC
Three options: H.265, H.264 and MJPEG.
Note:
The bit rate changes to the default when you change the setting between H.264
and H. 265. The default bit rate for H.265 is half of that for H.264.
Video Image Quality cannot be set when Video Compression is set to H.265 or
H.264. When Compression set to MJPEG, only three frame rates are available: 1, 3
and 5; and Bit Rate, I Frame Interval, Smoothing and U-Code cannot be set.
When Encoding Mode is VBR, you can move the slider to adjust quality
level for images. Moving the slider toward Bit Rate decreases the bit rate and may
aect image quality. Moving the slider toward Quality increases the bit rate and
improves image quality.
Frame rate for encoding images. Unit: FPS (frame per second).
Note:
To ensure image quality, note that the frame rate should not be greater than the
reciprocal of shutter speed.
4.Video and Image Setting
Click Setup > Video & Audio > Video.
4.1 Video Setting
- 08 -
You can set video parameters that your camera supports. If available,
you may also enable sub-stream and third stream as required.
CBR: Constant Bit Rate, which means that the camera transmits data at a constant
data rate.
VBR: Variable Bit Rate, which means that the camera adjusts the bit rate dynami-
cally according to image quality.
Interval at which an I frame is encoded. Normally, a shorter I frame interval oers
better image quality but consumes more bandwidth.
Group Of Pictures in MPEG video encoding. This parameter specifies the order in
which intra-frames (I frame) and inter-frames are arranged.
SVC (Scalable Video Coding) can reduce storage without compromising playback
quality.
