Place an empty bobbin winder spindle.
Take the thread from the spool through the
bobbin winder tension disc. (1)
Wind the thread a few times by hand around
the empty bobbin in a clockwise direction. Push
the bobbin to the right towards the bobbin
winding position. (2)
Press the foot control gently. The bobbin will
stop winding when it is full. Push the bobbin to
the left to “sewing position” and remove it.
Winding the bobbin
When the bobbin winder spindle is in “bobbin
winding” position, the machine will not sew and
the hand wheel will not turn. To start sewing,
push the bobbin winder spindle to the left
(sewing position).
NOTE:
a. Spool pin
12
