6
3.2 Location Requirements
• With the ingress of protection IP65, COM100 can be installed both indoors and
outdoors (more commonly).
• Ambient temperature: -25℃ to +60℃; and ambient humidity: ≤ 95%. Excessive
moisture can damage internal components.
• Take anti-moisture and anti-corrosion measures.
3.3 Installation Method
COM100 can be installed in two common manners: wall mounting and ground
mounting.
According to different user requirements, Sungrow provides the third optional
installation method: pole mounting. If necessary, specify your requirement when placing
an order.
Beware of the weight of COM100 throughout the installation process!
Tilting or falling of the device due to inappropriate processing can cause
personal injury!
3.3.1 Wall Mounting
The installation dimensions of mounting ears on the back of COM100 are shown in the
following figure.
step 1 Mark the hole locations on the installation wall according to the foregoing installation
dimensions and drill holes on the marked locations according to bolt specifications.
3 Mechanical Installation User Manual
