Sungrow COM100 - 5 Commissioning; 5.1 Inspection before Commissioning; 5.2 Commissioning Steps; Configure Logger3000 through WEB Interface

22
5
Commissioning
5.1 Inspection before Commissioning
NNoo.. IInnssppeeccttiioonn iitteemm
1 All cables are intact, well-insulated, and appropriately dimensioned.
2
All cables are connected correctly and firmly.
3 The polarity of the power supply cable is correct. The grounding cable is
reliably grounded.
5.2 Commissioning Steps
CCoommmmiissssiioonniinngg SStteeppss
IItteemm
DDeessccrriippttiioonn
1
Connect the input-side circuit breaker of the PLC inside COM100.
2
Connect the control switch of 220V power supply.
3
Check whether the switch and 24V switch-mode power supply operate
normally.
4
Observe running indicators of Logger3000. If the PWR indicator keeps
steady on, and the RUN indicator flickers once every second, it indicates
normal operation.
CCoonnffiigguurree LLooggggeerr33000000 tthhrroouugghh WWEEBB IInntteerrffaaccee
IItteemm
DDeessccrriippttiioonn
1
Connect PC to the Ethernet port of the switch inside COM100 by using a
network cable. IP of the Ethernet port is 13.13.13.13 by default.
2
Set IP of the PC, which should be in the same network segment as that of the
ETH2 port of the Logger3000. For example, it can be set to 13.13.13.x (x
ranges between 1 and 255, except 13), and the subnet mask can be set to
255.255.255.0.
3
Enter the IP of the Logger3000, such as 13.13.13.13, in the PC address bar,
to enter the corresponding Web interface.
4
Configure serial port parameters.
5
Add device.
6
Configure device IP.
