Appendix A: Related Parameters
CCoonnffiigguurraattiioonn
Logger Logger3000
Fibre channel switch
(Optional)
2 optical ports, 6 electrical ports
Splice box (Optional) 2-input, 12-ouput, SC single-mode
Power supply
100–277 Vac, 50/60 Hz
PLC port input voltage
400 Vac/480 Vac/540 Vac/800 Vac
PLC power supply voltage
• In-built master node of Logger3000: 15 Vdc
• Master node of PLC module: 24 Vdc
Power consumption
• Average power consumption: 30W
• Max. power consumption: 40W
Ambient parameter
Operating temperature
- 25℃ – +60℃
Storage temperature
- 30℃ – +70℃
Operating humidity
0–95%, non-condensing
Operating altitude
0–3,000 m
Protection degree IP65
Mechanical parameters
Dimensions (W x H x D) 570×790×190 mm
Weight 32 kg
Installation method Pole mounting, ground mounting, and wall mounting
Cable entry mode Bottom entry
