Sungrow EMS200 - WEB Interface; Login Preparations and Steps

20
8 WEB Interface
8.1 Requirements for Operation Environment
Item
Requirement
System
requirement
WIN7, WIN8, and WIN10
Browser version
IE10 to IE11 and CHROME43 to CHROME45
Minimum
resolution
1366*768
CPU
The clock speed is above 2.5G Hz
Memory
More than 4GB
8.2 Preparations for Login

Set IP address of the PC to be on the same network segment as that of the
local controller.

Connect the PC to the port ETH2 of the local controller.

The default IP address of the port ETH2 is 192.168.1.100. IP address of the
PC can be set to 192.168.1.125 when the subnet mask can be set to
255.255.255.0.
8.3 Login Steps
Step 1 Connect the local controller to the PC by using the Ethernet cable.
Step 2 Enter the IP address, for example, 192.168.1.100, of the local controller
in the PC address bar to enter the login interface shown in the picture
below.
Step 3 Enter the username and password, and click login.
