9
No. Label
Description
1 P-
The system negative terminal, connected to the hybrid inver-
ter negative terminal
2 P+
The system positive terminal, connected to the hybrid inverter
positive terminal
3 COMM
To enable the communication between the hybrid inverter and
the battery
4
Grounding terminal, connected to the ground
5
DC circuit
breaker
To connect/disconnect the DC circuit, for power-on, power-off,
and short-circuit protection
2.3 Symbols on the Product
Symbol Explanation
Pay attention to the danger. Do not operate this product in the live
status!
No open flames
Do not expose to flame, incinerate, puncture, or impact.
Electric shock hazard
Serviced by qualified personnel only. Out of reach from children.
TÜV mark of conformity
TÜV mark of conformity
CE mark of conformity
EU/EEA Importer
UKCA mark of conformity
Do not dispose in trash.
Compacting a lithium ion battery is dangerous as it can explode.
Please recycle this lithium ion battery. Do not discard.
Read the user manual before maintenance!
This is a protective grounding terminal, which should be grounded se-
curely to protect the safety of operators.
User Manual 2 Product Description
