43
Parameters SBR192 SBR224 SBR256
Over current
protection
Yes
Over / under tem-
perature protection
Yes
DC breaker Yes
General Data
Dimensions
(W*H*D)
625 * 935 * 330
mm
625 * 1065 * 330
mm
625 * 1195 * 330
mm
Weight 214 kg±3 kg 247 kg±3 kg 280 kg±3 kg
Installation location Indoor / Outdoor
Mounting method
Floor stand
Operating
temperature
Charge: 0 to 55℃
Discharge: -20 to 55℃
Degree of protection
IP55
Allowable relative
humidity range
0% to 95% no condensing
Max. operating
altitude
2000 m
Cooling method
Natural convection
Warranty
2
10 Years
Expansion
adaptation
Up to 4 units in parallel（need extra Combiner box）
1: Test conditions: 25℃,100% depth of discharge (DOD), 0.2C charge and discharge.
2: Refer to battery warranty card for conditional application.
3: SBR064 consits of 2 battery modules and 1 empty module.
9.2 FAQs
9.2.1 Battery Not Charging
1. Please wait 5~10 minutes for data refresh of iSolarCloud App.
2. If the problem persists, try charging the battery by enabling force mode. If the battery can
be charged now, please contact the hybrid inverter installer or manufacturer.
3. Check if the current battery SOC is the same as the set SOC upper limit of the hybrid in-
verter. Once the battery SOC reaches or goes beyond the SOC upper limit, the battery can-
not be charged (please set the value to 50~100 as needed).
4. If the problem is still not resolved, please check the system for any faults and take coun-
termeasures according to the fault code.
5. If the problem is still not resolved, check whether the ambient temperature is near or be-
low 0℃. Switch off the battery in the event of the temperature falling below 0℃, and restart
and charge it when the temperature rises up to over 5℃.
User Manual 9 Appendix
