Sungrow SBR064 User Manual

41
9
Appendix
9.1 Technical Data
table 9-1 Technical parameters of high voltage LFP battery(SBR064 / SBR096 / SBR128 / SBR160).
Parameters SBR064 SBR096 SBR128 SBR160
System Data
Battery Type
LiFePO4 Prismatic Cell
Battery Module 3.2 kWh, 33 kg
Energy (usable)
1
6.4 kWh 9.6 kWh 12.8 kWh 16 kWh
Nominal voltage
128 V 192 V 256 V 320 V
Operating voltage
108V-146 V 162 V– 219 V 216 V– 292 V
270 V– 365
V
Rated DC power
3.84 kW 5.76 kW 7.68 kW 9.60 kW
Max. charge/dis-
charge power
4.38 kW 6.57 kW 8.76 kW 10.95 kW
Max. charging /
discharging cur-
rent: continuous
30 A
Max. charging /
discharging
current:
42 A
Depth of Discharge Max. 100% DOD(settable)
Display
SOC indicator, Status indicator
Communication
interface
CAN
Protection
Over / under volt-
age protection
Yes
Over current
protection
Yes
Over / under tem-
perature protection
Yes
DC breaker Yes
General Data
Dimensions
(W*H*D)
625 * 545 *
330
mm
625 * 545 * 330
mm
625 * 675 *
330
mm
625 * 805 *
330
mm
Weight 91 kg±3 kg 115 kg±3 kg 148 kg±3 kg
181 kg±3
kg

Sungrow SBR064 Specifications

General

Battery Type	Lithium Iron Phosphate (LFP)
Nominal Voltage	51.2 V
Battery Module Energy	6.4 kWh
Operating Temperature	-10°C to 50°C
Communication	CAN/RS485
Protection Level	IP65
Scalability	Up to 8 modules in parallel
Cycle Life	6000 cycles @ 80% DoD
