2. Installation steps
2.1. Connect AC grid
Strip the AC cable and connect to the AC Grid plug as per the above wiring diagram
and click into place. Apply lock. (AC plugs are colour coded)
2.2. Connect Backup Circuit
Connect Backup AC in the same manner as the grid plug and click into the ‘Backup’
outlet.
Backup Grid
