7-34
[NOTE]
The number of needle bars (color changes) is indicated on the start menu screen.
Ex) Calling a design from memory #5 for repetition work with the parameters set as below
X REPETITION: 5 Y DESIGN INTERVAL: －40mm
Y REPETITION: 5 X/Y PRIORITY: X
X DESIGN INTERVAL: 40mm DESIGN INTERVAL: JUMP CODE
Call the design from #5 (see “7.4.1)
In and Out of Designs).
Press
Input “5”using the numerical key to
set the number of X repetitions.
Press
Input “5”using the numerical key to
set the number of Y repetitions.
Press
NO : 5
STITCH : 18294
COLOR : 7
JUMP : 7
==== REPEAT SETTING ====
1] X REPEAT
1 -> 99
=> ( 0)
==== REPEAT SETTING ====
2] Y REPEAT
1 -> 99
=> ( 0)
==== REPEAT SETTING ====
3] X Design Interval
-300
-
> +300[mm]
=> ( 0)
NO : 5
STITCH : 18294
COLOR : 7
JUMP : 7
To Next Page
