7-51
7-4-7) Frame Movement
(1) Moving Frame During Embroidery
Press when the operating system loads and you will see the following screen:
1. DATA ORIGIN
2. ORIGIN
3. POWER RESUME
4. FRAME ANGLE SET
A) Start point of embroidery
B) Stop point of embroidery
C) Frame moved by frame movement key
D) Frame moved by DATA ORIGIN
■■
DATA ORIGIN
Your SWF machine remembers the stopped position of the frame when it stops during operation (bar switch, thread
break detection, etc.) After you move the frame by frame movement key and do work, you can use the DATA
ORIGIN function to automatically move the frame back to the previously stopped location to resume embroidery
work.
(Frame moves back)
■■
ORIGIN (Start of embroidery)
This function moves the frame back to the first point of work.
A) Start point of embroidery
B) Stop point of embroidery
C) Frame moved by ORIGIN
To Next Page
