SUNWARD SWDM320HB - CRAWLER EXTENSION AND RETRACTION

SWDM320HB OPERATOR’S MANUAL
78
● Push the left and right pedal valves：
Foot Valve On 1
Position 2.1
Foot Valve on 2
Position 2.2
●Corresponding action schematic：
The left and right pedal
valves are pushed to
position 2.1
The left and right
pedal valves are
pushed to position
2.2
The right pedal
valves are pushed
to position 2.1
The left pedal valves are
pushed to position 2.1
