3.4 Operation and control of the machine
3.4.1 Operator’s position.
Operator is seated on the left hand in the cab.
It includes operator seat, seat belt, left/right joystick,
left/right pedal travel operating valve(joystick),
operation display screen, radio and .air
conditioning. .
3.4.2 Setting and adjustment.
The machine has the following settings:
Engine rev setting:
Turn the throttle knob to get desired revs.
Work mode setting：S、H、L
For detailed information, please refer to section
“3.2.5 monitor system”.
Travel speed setting：
Press travel speed switch button to shift
between high speed and low speed.
Auto-idle setting：
Press idle button to shift between “auto-idle”
and “auto-idle cancel”.
w
work mode shift flow
