5.1.2 Configuration specification
Machine specification SWE150F
A、 Wheel track 3000
B、 Track total length 3740
C、 Platform distance to ground 920
D、 Platform slewing radius 2350
E、 Upper structure width 2450
F、 Track gage 2000
G、 Chassis width 2600
H、 Track width 600
I、 Chassis distance to ground 470
J、 Cab roof height 2825
L、 Transportation length 7820
M、 Boom height 2850
Unit：mm
