5.1.5 Electric elements table
No. Name No. Name
1 work lamp 22 micro-switch
2 pressure switch 23 throttle knob
3 pressure sensor 24 work lamp switch
4 electric horn (top) 25 wiper switch
5 electric horn (bass) 26 front top switch
6 scrubber assembly 27 warning lamp switch
7 accumulator 120AH 28 control panel assembly
8 negative pole switch 29 radio
9 atmospheric pressure sensor 30 quick change locked switch
10 main relay 31 pressure selection switch
11 parking motor relay 32 wane switch cover plate
12 preheat relay 33 DPD manual regeneration wane
switch
13 start motor relay 34 fault code clear switch
14 ECM 35 jerk button
15 battery relay 36 after treatment generation indicator
lamp
16 dropping resistor 37 cigar lighter
17 display 38 flash buzzer
18 controller 39 rubber antenna
19 electric control box assembly 40 wiper motor
20 wiper controller 41 wiper jet
21 Middle excavator GPS 42 horn
