（1） There are four history failure record interface, first enter into interface 4-1,it recorded
content and times of history failure
（2） F2 can be switched among history failure
（3） F3 can realize switch between interface4-1 and interface 4-3。
（4） F4 can consult the detail time of failure, in interface 4-1 or 4-3 can switch to interface
4-2
（5） In interface4-1 and interface 4-3, F5 can clear history failure 。
（6） In interface4-4, F5 is used to confirm clear history failure。
（7） F1 is exit。
3.2.5.13 Throttle cablibration interface
Misoperation can lead to abnormal system, so please try your best to contact with Sunward
or the person who is authorized by Sunward to deal with it.
In this interface：
（1） First enter into password input interface, F4 select amended password digit capacity, F2
and F3 used to amend password. After inputting password, press F5, if password is
correct, enter into accelerograph calibration interface, F1 exit. 。
（2） There has min.accelerograph dial、max. accelerograph dial, calibrate state, engine rev
information and so on in the accelerograph calibration interface.
（3） Adjust accelerograph to min. position, press F2 to confirm, min. accelerograph dial is
confirmed.
（4） Adjust accelerograph to Max. position, press F3 to confirm, Max. accelerograph dial is
confirmed.
F1 F2 F5F3 F4
F1 F2 F3 F4
