2.2 ACCELERATOR PEDAL（PIC. B）
This pedal is used to vary the truck speed by modifying
the engine rpm rate.
2.3 FOOT BRAKE（PIC. A）
The foot brake control the brake that acts on the front A B
and rear wheels, thus slowing and stopping the lift truck.
2.4 STEERING WHEEL
Turning the stering wheel to control the direction of the
machine.There are three different steering module to choose.
You can use the regulating handle to adjust the height of the
steering wheel.
2.5 KEY SWITCH
Turn the key clockwise to .
OFF —stop condition
ON—put through power supply
PREHEAT—preheat the engine
START—start the engine(plus:start the engine in the neutral gear)。
2.6 EMERGENCY STOP SWITCH
Press the emergency stop switch at any time to stop all machine functions。
Turn switch clockwise to reset.
