2.1 INSTRUMENT PANEL
Fuel gage
Indicates the quantity of diesel available in the tank
Engine cooling water-thermometer dash unit
If the temperature reaches 103°C, the warning light turns on,
immediately turn off the engine and troubleshoot the cause in the
cooling circuit.
Load indicator
The indicator shows the machine load torque, when then load torque
is bigger than the set value, the pointer will point to the red zone,
built-in torque limiter will automatically cut off the action,that may
cause the risk of tipping.
Engine speed indicator
Checking the rotation speed of engine.
