16 17
3 Product Description
Figure 3-7 Packing list
Inspection
Report
User
Manual
Quick
Guide
User GuidePV Terminal×2
Monitoring Device×1(Optional)
AC Terminal×1 Ground Terminal×1
6Pin Terminal×1
②
3 Product Description
Note
① Export limitation & control version 2pcs; RS485 and DRED version 1 pcs (This connector
already pre-installed inside the inverter).
② STT 4-12kW 2pcs / STT 15kW 3pcs / STT 17-25kW 4pcs.
③ DRED version only (This connector already pre-installed inside the inverter).
④ L-shaped plate is optional, select according to needs.
③
④
L-shaped Plate(Optional)
To Next Page
