Chapter 2: Server Installation
21
Figure 2-3. Hanging Server on the Bracket
4.
lock it in place.
5. An additional bracket for a power adapter can be attached to the bottom of the chassis
bracket with a screw, as pictured below.
3. With the input/output ports facing up, hang the server on the mounting bracket by
hooking the four keyholes on the bottom of the chassis on the four knobs of the bracket.
Figure 2-4. Chassis Bracket with Power Adapter Bracket Attached
Power Adapter Bracket
Screw
