SuperServer E302-9A User's Manual
6. The power adapter can be secured to this lower bracket by partially unscrewing its latch,
sliding the latch upward, placing the power adapter in the bracket, lowering the latch,
and tightening the screw to secure it in place.
Figure 2-5. Power Adapter Bracket
Power Adapter Bracket Latch
Screw of Power Adapter Bracket Latch
