2-8
X10SRH-CF/CLN4F User’s Manual
OPEN 1st
OPEN 1st
OPEN 1st
Gently push
down to pop the
load plate open.
2. Press the second load lever labeled 'Close 1st' to release the load plate that
covers the CPU socket from its locking position.
3. With the 'Close 1st' lever fully retracted, gently push down on the 'Open 1st'
lever to open the load plate. Lift the load plate to open it completely.
1
2
Press down on Load
Lever 'Close 1st'
1
Pull lever away from
the socket
2
