Super X11DPH-i/X11DPH-T/X11DPH-Tq User's Manual
158
Step 2. Name:
This feature allows the user to enter the unique name of the RAID volume.
Step 3. RAID Level:
This feature allows the user to select the RAID level. The options are RAID0(Stripe),
RAID1(Mirror), RAID5(Parity), and RAID10(RAID0+1).
Note 1: The RAID level(s) displayed is(are) based on the number of NVMe devices
connected to the system.
Note 2: Use Intel® VROC Standard hardware key to support RAID 0/1/10. Use Intel®
VROC Premium hardware key (or Intel SSD Only hardware key) to support RAID
0/1/5/10.
