X11SPW-CTF/-TF User's Manual
Connector Description
LAN1, LAN2 10GbE LAN Ports
M.2 M.2 PCI-E 3.0 X4 or SATA 3.0 Slot
MH10, MH11 M.2 Mounting Holes
(L-)SAS0-3 Four SAS 3.0 Ports (with RAID 0, 1, 10) (X11SPW-CTF only)
(I-)SATA0~7 Intel® PCH SATA 3.0 Ports (with RAID 0, 1, 5, 10)
(S-)SATA0~1 SATA 3.0 Ports with SATA DOM Power
I-SGPIO1, I-SGPIO2, S-SGPIO1 Serial Link General Purpose I/O Headers
SXB1A, SXB1B, SXB1C Supermicro Proprietary WIO Left Add-on Card Slots
SXB2 Supermicro Proprietary WIO Right Add-on Card Slot
SP1 Internal Speaker/Buzzer
USB0/1 Back Panel Universal Serial Bus (USB) 2.0 Ports
USB2/3, USB4/5 Front Accessible USB 2.0 Headers
USB6 USB 2.0 Header (Not customized for the front panel)
USB7/8 Back Panel USB 3.0 Ports
USB9 USB 3.0 Type-A Header
USB10/11 Front Accessible USB 3.0 Header
VGA VGA Port
