X11SPW-CTF/-TF User's Manual

1.4 System Health Monitoring

Onboard Voltage Monitors

An onboard voltage monitor will scan the voltages of onboard chipset, memory, CPU, and

battery continuously. Once a voltage becomes unstable, a warning is given, or an error

message is sent to the screen. The user can adjust the voltage thresholds to dene the

sensitivity of the voltage monitor.

Fan Status Monitor with Firmware Control

The system health monitor embedded in the BMC chip can check the RPM status of the

cooling fans. The CPU and chassis fans are controlled via lPMI.

Environmental Temperature Control

System Health sensors monitor temperatures and voltage settings of onboard processors

and the system in real time via the IPMI interface. Whenever the temperature of the CPU or

the system exceeds a user-dened threshold, system/CPU cooling fans will be turned on to

prevent the CPU or the system from overheating.

Note: To avoid possible system overheating, please be sure to provide adequate air-

ow to your system.

System Resource Alert

This feature is available when used with SuperDoctor 5

in the Windows OS or in the Linux

environment. SuperDoctor is used to notify the user of certain system events. For example,

you can congure SuperDoctor to provide you with warnings when the system temperature,

CPU temperatures, voltages and fan speeds go beyond a predened range.

1.5 ACPI Features

ACPI stands for Advanced Conguration and Power Interface. The ACPI specication denes

a exible and abstract hardware interface that provides a standard way to integrate power

management features throughout a computer system, including its hardware, operating

system and application software. This enables the system to automatically turn on and off

peripherals such as CD-ROMs, network cards, hard disk drives and printers.

In addition to enabling operating system-directed power management, ACPI also provides a

generic system event mechanism for Plug and Play, and an operating system-independent

interface for conguration control. ACPI leverages the Plug and Play BIOS data structures,

while providing a processor architecture-independent implementation that is compatible with

Windows 2012/R2 and Windows Server 2016 operating systems.
